## Introduction [gRPC](https://grpc.io/) is a modern, high performance remote procedure call (RPC) framework that can be run in any environment. Built on [protocol buffers (commonly called protobufs)](https://protobuf.dev/), gRPC is extensible and, efficient, and has wide support in many languages and runtimes. You can take a look at our [what is gRPC post](/blog/what-is-grpc) to learn more. In this tutorial, we will go over how to deploy a React application backed by a Rust-based gRPC API to Koyeb. The demo application is a movie database website that feature showcases a selection of movies and their associated metadata. You can find the source for the two application components here: - [gRPC API written in Rust](https://github.com/filhodanuvem/movies-rust-grpc) - [React web frontend](https://github.com/filhodanuvem/movies-react) ## Prerequisites In order to follow along with this tutorial, you need the following: - A [Koyeb account](https://app.koyeb.com/auth/signup) to deploy the Rust and React services to. Koyeb's free tier allows you to run two services every month for free. - The [protobuf compiler](https://github.com/protocolbuffers/protobuf/releases/latest) installed on your local computer. We will use this to generate the language-specific stubs from our data format. - [Rust and `cargo`](https://www.rust-lang.org/learn/get-started) installed on your local computer to create the gRPC API service. - [Node.js and `npm`](https://nodejs.org/en/download) installed on your local computer to create the React-based frontend. Once you have satisfied the requirements, continue on to get started. ## Create the Rust API We will start by creating the Rust API for the backend and the protobuf file that defines the data format both of our services will use to communicate. ### Create a new Rust project and install the dependencies Start by defining a new Rust project. Use the `cargo` command to generate a new project directory initialized with the expected package files: ```bash cargo new movies-back ``` Next, move into the new project directory and install the project's dependencies: ```bash cd movies-back cargo add tonic@0.9.2 tonic-web@0.9.2 cargo add prost@0.11 prost-types@0.11 cargo add --build tonic-build@0.8 cargo add tonic-health@0.9.2 cargo add tower-http@0.2.3 cargo add --features tokio@1.0/macros,tokio@1.0/rt-multi-thread tokio@1.0 ``` By default, web browsers do not support gRPC, but we will use [gRPC-web](https://github.com/grpc/grpc-web) to make it possible. ### Define the data format Next, create the data format by creating a protobuf definition file. Create a new directory called `proto`: ```bash mkdir proto ``` Inside, create a new file named `proto/movie.proto` with the following contents: ```protobuf syntax = "proto3"; package movie; message MovieItem { int32 id = 1; string title = 2; int32 year = 3; string genre = 4; string rating = 5; string starRating = 6; string runtime = 7; string cast = 8; string image = 9; } message MovieRequest { } message MovieResponse { repeated MovieItem movies = 1; } service Movie { rpc GetMovies (MovieRequest) returns (MovieResponse); } ``` The `proto/movie.proto` file defines our data format using the [protobuf format](https://protobuf.dev/programming-guides/proto3/). It specifies a data structure to hold all of the data about a movie and outlines what a request and response for that data will look like. This definition will be used to define the API between our services. ## Create the backend service Now that we have our data format, we can create our backend service. Start by configuring the Rust build process to compile the protobuf file. Create a file called `build.rs` with the following content: ```rust fn main() -> Result<(), Box> { tonic_build::compile_protos("./proto/movie.proto")?; Ok(()) } ``` Now we can implement the actual API server with the `GetMovies` endpoint. Open the `src/main.rs` file and replace the contents with the following: ```rust use std::env; use tonic::{transport::Server, Request, Response, Status}; pub mod grpc_movie { tonic::include_proto!("movie"); } use grpc_movie::movie_server::{Movie, MovieServer}; use grpc_movie::{MovieRequest, MovieResponse}; #[derive(Debug, Default)] pub struct MovieService {} #[tonic::async_trait] impl Movie for MovieService { async fn get_movies( &self, request: Request, ) -> Result, Status> { println!("Got a request: {:?}", request); let mut movies = Vec::new(); movies.push(grpc_movie::MovieItem { id: 1, title: "Matrix".to_string(), year: 1999, genre: "Sci-Fi".to_string(), rating: "8.7".to_string(), star_rating: "4.8".to_string(), runtime: "136".to_string(), cast: "Keanu Reeves, Laurence Fishburne".to_string(), image: "http://image.tmdb.org/t/p/w500//aOIuZAjPaRIE6CMzbazvcHuHXDc.jpg".to_string(), }); movies.push(grpc_movie::MovieItem { id: 2, title: "Spider-Man: Across the Spider-Verse".to_string(), year: 2023, genre: "Animation".to_string(), rating: "9.7".to_string(), star_rating: "4.9".to_string(), runtime: "136".to_string(), cast: "Donald Glover".to_string(), image: "http://image.tmdb.org/t/p/w500//8Vt6mWEReuy4Of61Lnj5Xj704m8.jpg".to_string(), }); movies.push(grpc_movie::MovieItem { id: 3, title: "Her".to_string(), year: 2013, genre: "Drama".to_string(), rating: "8.7".to_string(), star_rating: "4.1".to_string(), runtime: "136".to_string(), cast: "Joaquin Phoenix".to_string(), image: "http://image.tmdb.org/t/p/w500//eCOtqtfvn7mxGl6nfmq4b1exJRc.jpg".to_string(), }); let reply = grpc_movie::MovieResponse { movies: movies }; Ok(Response::new(reply)) } } #[tokio::main] async fn main() -> Result<(), Box> { let port = env::var("PORT").unwrap_or("50051".to_string()); let addr = format!("0.0.0.0:{}", port).parse()?; let movie = MovieService::default(); let movie = MovieServer::new(movie); let movie = tonic_web::enable(movie); let (mut health_reporter, health_service) = tonic_health::server::health_reporter(); health_reporter .set_serving::>() .await; println!("Running on port {}...", port); Server::builder() .accept_http1(true) .add_service(health_service) .add_service(movie) .serve(addr) .await?; Ok(()) } ``` The application uses the [tonic gRPC implementation](https://docs.rs/tonic/latest/tonic/) to build and serve the API for our backend based on the structures and interfaces defined by the protobuf file. In a real world scenario, this would typically be backed by a database containing the movie data, but to simplify the implementation, we just include data for a few movies inline. The service will run on port 50051 by default (modifiable with the `PORT` environment variable) and will respond for requests for movies using with response objects as defined by the protobuf file. ### Test the API backend The API backend is now complete, so we can start the server locally to test its functionality by typing: ```bash cargo run ``` The API server will be built and start running on port 50051. You can test the functionality using a gRPC client of your choice like [`grpcurl`](https://github.com/fullstorydev/grpcurl) or [Postman](https://postman.com/). For example, you can request the list of movies using `grpcurl` by typing the following in your project's root directory with the Rust service running: ```bash grpcurl -plaintext -import-path proto -proto movie.proto 127.0.0.1:50051 movie.Movie/GetMovies ``` The service should return the list of movies as expected: ```json { "movies": [ { "id": 1, "title": "Matrix", "year": 1999, "genre": "Sci-Fi", "rating": "8.7", "starRating": "4.8", "runtime": "136", "cast": "Keanu Reeves, Laurence Fishburne", "image": "http://image.tmdb.org/t/p/w500//aOIuZAjPaRIE6CMzbazvcHuHXDc.jpg" }, { "id": 2, "title": "Spider-Man: Across the Spider-Verse", "year": 2023, "genre": "Animation", "rating": "9.7", "starRating": "4.9", "runtime": "136", "cast": "Donald Glover", "image": "http://image.tmdb.org/t/p/w500//8Vt6mWEReuy4Of61Lnj5Xj704m8.jpg" }, { "id": 3, "title": "Her", "year": 2013, "genre": "Drama", "rating": "8.7", "starRating": "4.1", "runtime": "136", "cast": "Joaquin Phoenix", "image": "http://image.tmdb.org/t/p/w500//eCOtqtfvn7mxGl6nfmq4b1exJRc.jpg" } ] } ``` ### Create a Dockerfile When we deploy the backend to Koyeb, the application will be run in a container. We can define a `Dockerfile` for our project to describe how the project's code should be packaged and run. In the project's root directory, create a new file called `Dockerfile` with the following content: ```dockerfile FROM rust:1.64.0-buster as builder # install protobuf RUN apt-get update && apt-get install -y protobuf-compiler libprotobuf-dev COPY Cargo.toml build.rs /usr/src/app/ COPY src /usr/src/app/src/ COPY proto /usr/src/app/proto/ WORKDIR /usr/src/app RUN rustup target add x86_64-unknown-linux-musl RUN cargo build --target x86_64-unknown-linux-musl --release --bin movies-back FROM gcr.io/distroless/static-debian11 as runner # get binary COPY --from=builder /usr/src/app/target/x86_64-unknown-linux-musl/release/movies-back / # set run env EXPOSE 50051 # run it CMD ["/movies-back"] ``` When you are finished, add all of the files for the API to a new GitHub repository so that we can deploy it to production later. We are ready now to create the react application that will consume the API. ## Create the React application Now that the backend is complete, we can begin working on the React frontend service for our application. ### Generate a new React project The fastest way to create a basic react application is with the `create-react-app`. Check to make sure you are not in the Rust service's directory and then type: ```bash npx create-react-app movies-front ``` This will a new project directory for your frontend and generate some basic files to help you get started. Move into the new directory and start the service to validate that everything installed correctly: ```bash cd movies-front npm run start ``` A development server will open on port 3000 and React will attempt to open a new browser window to view it. You can visit `localhost:3000` if you are not automatically directed there. The default React development page should appear: ![The default landing page for a new React project](/static/images/tutorials/grpc-multi-tier/react_default_landing_page.png) Press Ctrl-c when you are finished to stop the development server. ### Configure the Tailwind CSS framework Our react application will show a list of movies on a page. To speed up the process of styling it, we are going to use [Tailwind CSS](https://tailwindcss.com/). Install the necessary packages and initialize Tailwind by typing: ```bash npm install -D tailwindcss postcss autoprefixer npx tailwindcss init -p ``` Now that Tailwind is installed, we need to configure the React application to support it. First, open the `tailwind.config.js` file. Modify the `content` property to pick up all of our expected CSS content: ```javascript /** @type {import('tailwindcss').Config} */ module.exports = { content: ['./src/**/*.{js,ts,jsx,tsx,mdx}'], theme: { extend: {}, }, plugins: [], } ``` We will be using Sass instead of CSS directly, so we need to install the `sass` package next: ```bash npm install sass ``` Remove the `src/App.css` file and replace it with an `src/App.scss`. Inside, we import all of the Tailwind code that we require: ```css @tailwind base; @tailwind components; @tailwind utilities; ``` We can test Tailwind by changing the main React application file. Change the contents of the `src/App.js` file like this: ```javascript import './App.scss' import Movie from './Movie' function App() { // for now we will let movies = [ { id: 1, title: 'The spiderman across the spider verse', year: 2023, genre: 'animation', rating: 'L', starRating: '4.9', runtime: '2h 22min', cast: 'Donald Glover', image: 'http://image.tmdb.org/t/p/w500//8Vt6mWEReuy4Of61Lnj5Xj704m8.jpg', }, ] return (

{movies.map((movie) => ( ))}

) } export default App ``` Here, we create an application that will serve our movie list when the page is requested. At this point, we just mock up a single movie so that we can test our CSS styling. Create a `src/Movie.js` file to define how the movie should be styled and displayed: ```javascript export default function Movie(props) { let movie = props.details return (

{movie.title}

Star rating: {movie.starRating}
Rating: {movie.rating}
Year: {movie.year}
Genre: {movie.genre}
Runtime: {movie.runtime}
Cast: {movie.cast}

) } ``` If you start up the development server again, you should be able to see the movie mocked out: ```bash npm run start ``` ![Single movie mock display](/static/images/tutorials/grpc-multi-tier/dummy_movie_display.png) ### Fetch movie lists from the API Next, instead of displaying a hardcoded movie, we will modify the application to fetch data from the gRPC API. First, install protobuf and gRPC web support for React: ```bash npm install google-protobuf@~3.21.2 grpc-web@~1.4.1 ``` Next, we need to generate the movie entity in JavaScript based on the same protobuf file we defined for the backend Rust application. To do this, we will use the `protoc` command included in the protobuf installation from the prerequisites. Assuming the `movies-back` and `movies-front` are located next to each other, you can generate the appropriate JavaScript files with the protobuf definition by running the following command in the `movies-front` directory: ```bash # change the proto_path to the correct place where movie.proto is. protoc --proto_path=../movies-back/proto/ movie.proto --grpc-web_out=import_style=commonjs,mode=grpcweb:src --js_out=import_style=commonjs,binary:src ``` This will generate the appropriate JavaScript stubs from your protobuf file so that the React application understands how to communicate with the API. Now we can change the `src/App.js` file to use gRPC instead of serving a hardcoded movie: ```javascript import { useEffect, useState } from 'react' import './App.scss' import Movie from './Movie' const proto = {} proto.movie = require('./movie_grpc_web_pb.js') function App() { let url = process.env.REACT_APP_BACKEND_URL if (url == null) { url = 'http://localhost:50051' } const client = new proto.movie.MovieClient(url, null, null) let [movies, setMovies] = useState([]) useEffect(() => { const req = new proto.movie.MovieRequest() client.getMovies(req, {}, (err, response) => { if (response == null) { return } if (response.getMoviesList().length === 0) { return } let m = [] response.getMoviesList().forEach((movie) => { console.log(movie.toObject()) m.push(movie.toObject()) }) setMovies(m) }) }, []) return (

{movies.map((movie) => ( ))}

) } export default App ``` Start the development server again to test the new changes: ```bash npm run start ``` This time, you should see the full movie list as served from the API backend: ![Full movie display from backend API](/static/images/tutorials/grpc-multi-tier/full_movie_display.png) After confirming that the application works as expected, add the React app's files to a new GitHub repository and push them. We will deploy the application to production in the next stage. ## Deploy the application to Koyeb Now that our frontend and backend are working as expected, we can deploy both services to Koyeb. ### Deploy the API service First, we will deploy the Rust application to Koyeb. On the **Overview** tab of the [Koyeb control panel](https://app.koyeb.com/), click the **Create Web Service** button to get started: 1. Select **GitHub** as your deployment method. 2. Select the repository for the backend API from your repository list. Alternatively, you can use the example repo for this service which contains the same code we've discussed by putting `https://github.com/filhodanuvem/movies-rust-grpc` in the **Public GitHub repository** field. 3. In the **Builder** section, choose **Dockerfile**. 4. In the **Exposed ports** section, change the port value to **50051** and select **HTTP/2** from the protocol list. Set the path to `/api`. 5. Click **Deploy**. ![Koyeb API deployment configuration](/static/images/tutorials/grpc-multi-tier/koyeb_api_deploy.png) ![Koyeb API port and health check configuration](/static/images/tutorials/grpc-multi-tier/koyeb_api_port_config.png) On the API's service page, copy the value of the **Public URL**. We will need this value when configuring our React application. ## Deploy the React application Now that the API is running we can deploy the React application. Unlike the API, we will use the buildpack builder for this project rather than building from a Dockerfile. In the **Apps** tab of the [Koyeb control panel](https://app.koyeb.com/), click on the application that includes the API service you just deployed. From the service's index page, click the **Create Service** button to deploy an additional service within the context of the same Koyeb App: 1. Select **GitHub** as the deployment method. 2. Select the repository for the frontend React application from your repository list. Alternatively, you can use the example repo for this service which contains the same code we've discussed by putting `https://github.com/filhodanuvem/movies-react` in the **Public GitHub repository** field. 3. In the **Environment variables** section, click the **Add variable** button and create a new variable called `REACT_APP_BACKEND_URL`. Use the API service's public URL that you copied as the value. It should look something like the following: `REACT_APP_BACKEND_URL=https://-.koyeb.app/api`. 4. Click **Deploy**. ![Koyeb frontend deployment configuration](/static/images/tutorials/grpc-multi-tier/koyeb_frontend_deploy.png) ![Koyeb frontend environment variable configuration](/static/images/tutorials/grpc-multi-tier/koyeb_frontend_env_vars.png) ## Conclusion In this guide, we created and deployed an end-to-end application composed of a Rust backend and a React frontend. The two services communicate using gRPC. We deployed both services to Koyeb to take advantage of its native gRPC support. The services are able to communicate securely in order to fulfill user requests for the movie database site. If you have any questions or suggestions, feel free to reach out on our [community Slack](https://slack.koyeb.com/).
